DS18 GEN-X112LD Bass Package GEN-X124D 12" Subwoofer In a Ported Box 900 Watts

If you are looking for a lot of thumping bass and a very clean prefab box, we here at DS18 have developed a very strong combo to fit one of our bestselling speakers that we have to offer in a complete box! Now you don have to worry about building a box by yourself to spec for your new subwoofer purchase because you can buy them together with 1 easy click of the mouse.

This beautiful ported box is tuned to 35Hz and has an internal volume of 1.5 cubic feet for the. The ½ inch thick treated MDF ensures the box will be tough enough to withstand very strong vibrations along with giving very accurate acoustical resonances for the perfect bass response. Inside the box is one of our best-selling subs, the GEN- X12D subwoofer.

This high excursion sub has a 67 oz ferrite magnet and can take up to 450 watts RMS each and 900w maximum power! With a 4+4 configuration on the 2 inch 4-layer voice coil, you will have no problem making power out of your amplifier because in parallel the final load will be optimal and with a sensitivity of 87.5db. With this you won miss out on any of the wide range of frequencies this sub and box combo can produce! The only thing you will need is the amplifier to drive them and you are ready to go!

Highlights

• Best selling GEN -X12.4D sub giving you amazing low bass and great wattage handling.
• High Quality prefabricated DS18 subwoofer box that not only looks great but brings out low and loud bass easily.
• Ported design with an internal volume of 3.2 CD plus port volume which is tuned to 35hz.

Technical Details

Download GEN-X112LD Product Manual

General
Total Impedance	2 Ohms
Total RMS Power Handling	450W
Total MAX Power Handling	900W
Sensitivity (1w/1m)	91dB
Frequency Response	29 - 250Hz
Recommended Lo Pass Crossover	120Hz
Speaker Specifications
1 x 12" GEN-X124D Subwoofer
Voice Coil Diameter	2"
Voice Coil Former Material	Black Aluminum
Winding Material	SV
Cone Material	Paper & Fiber Glass
Dust Cap Material	PPI
Surround Material	Foam
Basket Material	Steel
Magnet Material	Ferrite
Magnet Weight	70 Oz
Box Specifications
Internal Volume	45.3L
Port Tune	35Hz
Load Configuration	Parallel
Box Type	Front Ported
Box Material	1/2" MDF
Finish Material	Vinyl
-3dB Dropping Point	29Hz
Measurement
Height	13.78” / 350mm
Width	19.68” / 500mm
Depth 1	11” / 280mm
Depth 2	14” / 356mm
