INFINITE 55 AH AGM Power Cell 12 Volt Battery

INFINITE 55 AH AGM Power Cell 12 Volt Battery

Regular price $257.95
Vendor:DS18
Type:Batteries
SKU:INF-55
In stock

Sale Ends September 21st
Minimum Purchase of $349.00
*Applies to Mechman & XS Power Products ONLY
Quantity
Payment Options
Description Reviews

    DS18 INF-55AH INFINITE 55 AH 1750 Watts AGM Power Cell 12 Volt Battery

     DS18 Infinite AGM power-cell batteries are what real enthusiasts need for all their charging system needs. These batteries have been proven tough and able to withstand extreme amperage draws and hold strong voltage through the most demanding of times. This AGM (absorbed glass mat) technology has proven through the years to be the most cost effective way to meet high charging demands from any 12v sources. Packed in a durable container, this battery is sure to stand the test of time. These batteries have a higher than normal float voltage so with the vehicle on and the alternator charging these will give even more reserve.

    Highlights

    • AGM (Absorbed Glass Mat) design that has proven itself through time and is the number one choice among team competitors.
    • Non spill design so the batteries can be mounted upside down or in multiple configurations without worry.
    • Bolt M5 terminals for secure connection also giving multiple options for add on terminals and busbars for the highest connectivity and conduction.
    • High burst reserve so the battery can maintain high volumes of amperage draw while efficiently holding voltage.
    • High float charge so your lights stay brighter, your electronics run stronger, and you have more reserve power and voltage altogether.



    Technical Details
    Specifications
    Battery Type AGM
    Nominal Voltage 12.8 V
    Capacity  55Ah @ 10hr-rate to 1.8V per cell @ 25°C (77°F)
    Maximum Discharge Current  1650 Amps
    Cranking Amps (CA) 825 Amps
    Cold Cranking Amps (CCA) 400 Amps
    Watts (RMS) 1750W
    Internal Resistance Approx. 6.5 mΩ
    Float Charging Voltage 13.5 to 13.8 Vdc / unit average at 25°C (77°F)
    Recommended Charging Current 16.5 Amps
    Nominal Operating Temperature Range 25°C +/- 3° (77°F +/- 5°)
    Bolt / Terminal Type Theard Lead Alloy Recessed / M6 Bolt
    Battery Group U1
    Measurement
    Overall Length 9" / 230mm
    Overall Width 5.43" / 138mm
    Overall Height 8.46" / 215mm
    Overall Height (Without Terminals) 8.26" / 210mm
    Weight 36.30 Lbs / 16.5 kg
